Engine Stop Momentary Push-Button Switch – SPST, Off-(On), 2 Screws (Red)
Part #: CH-90048
Housing Material: Zinc die-cast
Actuator: Plastic plunger with “Engine Stop” imprint
Circuitry: SPST
Voltage Ratings: 35A at 12V
Positions: Off-Momentary On (normally off/open, spring return to off)
Input Terminal Style: 2 screws
Contacts: Silver
Panel Hole Diameter: 0.04 – 0.1 in / 1 – 2.5 mm
Similar Products
Heavy Duty Momentary Push-Button Switch – SPST, Off-(On), 2 Leads
Part #: CH-90043-07
Heavy Duty Momentary Push-Button Switch – SPST, Off-(On), 2 Screws
Part #: CH-09095
Momentary Push-Button Switch – SPST, Off-(On), Solder Lug
Part #: PBS-MSPS103C0
Light Duty Momentary Push-Button Switch – SPST, Off-(On), 2 Screws
Part #: CH-09109
Marine Momentary Push-Button Switch – SPST, Off-(On), 2 Leads
Part #: CH-M608
